ADG-SSY-81242-42U

42U Servers Rack
Size - W-800- D-1200, H-2055 mm
The cabinet can be supplied in different sizes (depth & height) according to customer's demand.
ADG-SSY-81242-42U

Description-
The Cabinet specially designed for network servers in high density in IT environment. The cabinet
made of cold rolled steel.

Application-
Store and secure servers, data storage, network equipment in the data center, computer room or
network environment.

Specifications-

  • Adjustment Mounting Rails
  • The cabinet made of steel
  • 19" suitable
  • Removable side panel and front door
  • Maximum static load 1000 kg
  • IP20

Contain-

  • Top cover
  • Bottom panel
  • Frame
  • Vented front door
  • Vented rear door
  • 2 Side panel
  • Horizontal beam
  • Vertical rail
  • 4 Casters (2 with brake)
  • 4 Leveling feed
  • 4 Fans
  • 2 vertical cable management

Optional Accessories-

  • Fixed shelf
  • Sliding shelf
  • Cable management
  • Cooling solution
  • Airflow Management
  • PDU

Standards-

  • ANSI/ EIA RS-310-D. IEC297-2. DIN1494, PART 1 . DIN41494, PART 7. GB/T3047:2-92STANDARD
  • IP20



Specification


Specification ADG-SSY-81242-42U HE
