SGS-6341-48T4X

מוצר קודם
תיאור מוצר
Layer 3 48-Port 10/100/1000T + 4-Port 10G SFP+ Stackable Managed Switch

Physical Ports
  • 48 10/100/1000BASE-T Gigabit Ethernet RJ45 ports
  • 4 10GBASE-SR/LR SFP+ slots, compatible with 1000BASE-SX/LX/BX SFP
  • RJ45 to DB9 console interface for switch basic management and setup
IP Stacking
  • Connects with stack member via both Gigabit TP and SFP interfaces
  • Single IP address management, supporting up to 24 units stacked together
IP Routing Features
  • IP routing protocol supports RIPv1/v2, RIPng, OSPFv2/v3, BGP4/4+
  • Routing interface provides per VLAN routing mode
  • VRRPv1/v3 protocol for redundant routing deployment
  • Supports route redistribution
  • Multicast Routing Features
  • Supports PIM-DM (Protocol Independent Multicast – Dense Mode) and PIM-SM (Protocol Independent Multicast – Sparse Mode) and PIM-SSM (Protocol Independent Multicast – Source Specific Multicast)
  • Supports DVMRP (Distance Vector Multicast Routing Protocol)
  • Supports IGMP v1/v2/v3 and MLD v1/v2
Layer 2 Features
  • Complies with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z Gigabit Ethernet standard
  • Supports auto-negotiation and half-duplex/full-duplex modes for all 10BASE-T, 100BASE-TX and 1000BASE-T ports
  • Auto-MDI/MDI-X detection on each RJ45 port
  • Prevents packet loss flow control
  • - IEEE 802.3x pause frame flow control in full-duplex mode
  • - Back-pressure flow control in half-duplex mode
  • High performance Store-and-Forward architecture, broadcast storm control, port loopback detect
  • 16K MAC address table, automatic source address learning and aging
  • Supports VLAN
  • - IEEE 802.1Q tag-based VLAN
  • - GVRP for dynamic VLAN management
  • - Up to 256 VLANs groups, out of 4041 VLAN IDs
  • - Provider Bridging (VLAN Q-in-Q, IEEE 802.1ad) supported
  • - Private VLAN Edge (PVE) supported
  • - GVRP protocol for Management VLAN
  • - Protocol-based VLAN
  • - MAC-based VLAN
  • - IP subnet VLAN
  • Supports Link Aggregation
  • - Maximum 12 trunk groups, up to 8 ports per trunk group
  • - IEEE 802.3ad LACP (Link Aggregation Control Protocol)
  • - Cisco ether-channel (static trunk)
  • Supports Spanning Tree Protocol
  • - STP, IEEE 802.1D (Classic Spanning Tree Protocol)
  • - RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)
  • - MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)
  • - Supports BPDU & root guard
  • Port mirroring to monitor the incoming or outgoing traffic on a particular port (many to many)
  • Provides port mirror (many-to-1)
Quality of Service
  • 8 priority queues on all switch ports
  • Support for strict priority and WRR (Weighted Round Robin) CoS policies
  • Traffic classification
  • - IEEE 802.1p CoS/ToS
  • - IPv4/IPv6 DSCP
  • - Port-based WRR
  • Strict priority and WRR CoS policies
Multicast
  • Supports IPv4 IGMP snooping v1, v2 and v3; IPv6 MLD v1 and v2 snooping
  • Querier mode support
  • Supports Multicast VLAN Register (MVR)
Security
  • IEEE 802.1x port-based network access authentication
  • MAC-based network access authentication
  • Built-in RADIUS client to cooperate with the RADIUS servers for IPv4 and IPv6
  • TACACS+ login users access authentication
  • IP-based Access Control List (ACL)
  • MAC-based Access Control List
  • Supports DHCP snooping
  • Supports ARP inspection
  • IP Source Guard prevents IP spoofing attacks
  • Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
Management
  • Management IP for IPv4 and IPv6
  • Switch Management Interface
  • - Console/Telnet Command Line Interface
  • - Web switch management
  • - SNMP v1, v2c, and v3 switch management
  • - SSH/SSL secure access
  • BOOTP and DHCP for IP address assignment
  • Firmware upload/download via TFTP or HTTP Protocol for IPv4 and IPv6
  • SNTP (Simple Network Time Protocol) for IPv4 and IPv6
  • User privilege levels control
  • Syslog server for IPv4 and IPv6
  • Supports DDM
  • Four RMON groups 1, 2, 3, 9 (history, statistics, alarms and events)
  • Supports sFlow
  • Supports ULDP
  • Supports ULPP (Uplink Protection Protocol)
  • Supports ULSM (Uplink State Monitor protocol)
  • Supports LLDP/LLDP MED
  • Supports DHCP Option82, Option37/38
  • Supports ping, trace route function for IPv4 and IPv6



Specification
