DDRH-240-48 MEAN WELL

DDRH 120/240 series’key features include: 250~1500Vdc ultra-high input DIN rail which can supply stable working voltage for the load.

• 250~1500Vdc ultra-wide input range
• 4KVac I/O isolation
• Free air convection, can operate between -40~+80℃ (+55℃@full load without derating), suitable for various installation conditions
• Half encapsulated, helps with heat dissipation, 3G anti-vibration, and dust + moisture resistance
• Fanless design, no noise
• Excellent EMC performance, meet EN55032 Class A EMI performance without external components
• Approvals: CB, DEKRA (IEC/EN62109-1), EAC, CE, UKCA
• Warrenty: 3 years

Specification DDRH-240-48
