SPF+DAC-0.5M SPF+DAC-2M

The DAC SFP+ cable assemblies are high-performance, cost effective I/O solutions for 10Gb Ethernet
and 10G Fibre Channel applications. SFP+ passive copper modules allow hardware manufacturers to
achieve high port density, configurability and utilization at a very low cost and to reduce power
budget. The high-speed cable assemblies meet and exceed the performance and reliability
requirements stipulated by Gigabit Ethernet and Fibre Channel industry standard.

• Support for multi-gigabit data rates up to 10.5Gbps
• Data rates backward compatible to 1Gbps
• Hot-pluggable SFP 20PIN footprint
• I/O Connector designed for high speed differential signal applications
• Improved Pluggable Form Factor(IPF) compliant for enhanced EMI/EMC performance
• Compatible to SFP+ MSA
• Temperature Range: 0~ 70 °C
• Comply with RoHS 2.0
